Vehicle category

Tractor truck

 Driving type

4*2

Product platform

N6

 Steering wheel position

Left hand

 Vehicle Model

CGC4180D5CAAA

Vehicle dimension parameters

Wheelbase

3500

Vehicle dimension ( L × W × H )

6035×2500×3000

Wheel track ( front / rear )（mm）

2037/1860

Vehicle quality parameters

Gross vehicle weight（kg）

15975

Max designed gross vehicle weight ( kg )

16500

Curb weight (kg)

6080

Design traction quality(kg)

35000

Vehicle performance parameters

Max. speed

90

Max. gradeability ,% ( full load )

20

Cabin

Type

N6 flat roof short row semi-narrow body tractor cab

Carrying capacity

3

Engine

 Brand

Weichai

 Model

WP6.245E50

Max power (ps)

245

 Series

EURO V

Displacement (L)

6.75

 Rated rpm

2300

Clutch

Type

 /

 Plate parameter (mm)

∮430

Gearbox

Brand

Fast

Model

8JS105T

 Gear ratio

/

 Structural style

Pull line

Braking

ABS

This vehicle Without ABS

Front axle

Rated load

6500 kg

Brake type

Drum-type braking

Front leaf spring

3

Middle / rear axle

 Tonnage

10000 kg

Structure

Drum-type braking

 Gear ratio

i=4.875

Rear leaf spring

4+3

Tire

 Plate parameter (mm)

11R22.5

(Comply with E4 European standard)

 Quantity

6

Fuel tank

Specifications and Materials

350L Aluminum alloy

Function configuration

Front wheel cover to prevent splashing, split rear wheel cover, four-point spring structure cab, 1+2 (split seat), driver's airbag seat, single sleeper, manual door lock, manual rearview mirror, electric glass lift，manual hydraulic lift pump, intercooler protection device, front lower protection device, full floating body suspension, manual air conditioning (only cooling), radio, no top shroud，Aluminum alloy air reservoir

Installation configuration

50# fifth wheel
